| No. | Item | Unit | Parameter |
|---|---|---|---|
| 1 | Air Flow | m³/min | 57.3 |
| 2 | Discharge Pressure | bar | 1.4 |
| 3 | Unit Internal Temperature | ℃ | < 105 |
| 4 | Discharge Air Temperature | ℃ | Ambient + (5～8) |
| 5 | Max. Inlet Air Temperature | ℃ | 45 |
| 6 | Cooling Method | - | Air-cooled |
| 7 | Transmission Type | - | Direct drive |
| 8 | Residual Oil Content | ppm | 0 |
| 9 | Power Supply | - | 380V · 3 Phase |
| 10 | Motor Power | kW | 132 |
| 11 | Motor Insulation Class | - | F |
| 12 | Motor Protection Class | - | IP55 |
| 13 | Unit Dimensions (L×W×H) | mm | 3100×1390×2070 |
| 14 | Motor Speed | rpm | 3000 |
| 15 | Control Mode | - | PLC |
