110kw Two Stage Pm Inverter Type Electric Drive Air Compressor 8bar Screw Air Compressor
Energy-Efficient & Reliable Performance Our Permanent Magnet Variable Frequency Integrated Screw Air Compressor delivers maximum efficiency, quiet operation, and long-term cost savings for industrial and commercial applications. Key Advantages: ✔ Superior Energy Savings – Advanced permanent magnet motor technology, paired with an integrated variable frequency drive (VFD), adjusts power to match demand, reducing energy consumption by up to 30-40%. ✔ Stable & Reliable Performance – Consistent airflow with minimal pressure fluctuations, ensuring smooth operation for sensitive applications. ✔ Low Maintenance & Long Lifespan – Durable design with fewer moving parts decreases wear and extends service intervals. ✔ Quiet Operation – Optimized for reduced noise, ideal for noise-sensitive environments. Ideal for: Manufacturing, automotive, food & beverage, and other industries requiring high-efficiency, cost-effective compressed air solutions. Invest in smarter energy use and reliable performance—with minimal downtime and lower operating costs.
Send Inquiry

Product Description

Technical Specifications
Permanent Magnet Motor (PM Motor)
Offers ultra-high efficiency, significantly lowering power consumption compared to traditional induction motors.
Integrated Variable Frequency Drive (VFD)
Automatically adjusts motor speed to match air demand, eliminating energy waste from unloading cycles.
Low Noise & Vibration
Optimized screw rotor design and soundproof enclosure ensure quiet operation (as low as 65 dB).
Compact & Space-Saving Design
Fully integrated unit with built-in cooling system, reducing installation footprint.
Smart Control System
User-friendly LCD touchscreen with real-time monitoring, fault alerts, and remote control capability.
High-Quality Components
Premium bearings, corrosion-resistant rotors, and efficient filtration ensure long service life and minimal downtime.
Key Features & Applications
Ideal for manufacturing, automotive, textiles, food & beverage, pharmaceuticals, and electronics industries, where stable air supply and energy efficiency are critical.
30-40% Energy Savings Reduces operational costs with superior efficiency.
Maintenance-Free PM Motor No brushes or slip rings, ensuring long-term reliability.
Plug-and-Play Installation Pre-assembled design for quick setup.
1-Year Motor Warranty Confidence in quality and durability.
Model & Specifications Table
Model ETSVII-22A ETSVII-37A ETSVII-45A ETSVII-55A ETSVII-75A ETSVII-90A ETSVII-110A ETSVII-132A
Air Flow & Pressure (m³/min / MPa) 0.7 MPa 4.1 6.9 8.9 11.2 15.1 20.0 22.0 26.0
0.8 MPa 4.0 6.8 8.8 11.0 15.0 19.8 21.2 25.8
1.0 MPa 3.4 6.2 7.8 9.7 12.4 17.9 19.8 23.5
Air Supply Temp. ≤ ambient temperature +8~15°C
Motor Details
Motor Power (kW/HP) 22/30 37/50 45/60 55/75 75/100 90/120 110/150 132/175
Start Method VSD Start
Voltage 380V 3PH 50HZ (other voltages can be customized)
Physical & General Specifications
Drive Method Integrated air end and motor
Oil Content (PPM) ≤ 3
Connector (Inch) 1" 1 1/2" 2" 2" 2" 2 1/2" 2 1/2" 2 1/2"
Dimensions (mm) Length (L) 1254 1455 1754 7854 1914 2454 2454 2454
Width (W) 900 1100 1200 1300 1300 1500 1500 1500
Height (H) 1190 1300 1550 1550 1600 1840 1840 1840
Weight (kg) 450 580 925 970 1170 1746 1750 1790
Frequently Asked Questions
Q1: What are the main benefits of a Permanent Magnet (PM) Motor?
A PM Motor offers ultra-high operating efficiency and significantly lowers power consumption compared to traditional induction motors, saving you money over time.
Q2: How does the Variable Frequency Drive (VFD) save energy?
The integrated VFD automatically adjusts motor speed to match your actual air demand, completely eliminating energy waste associated with unloading cycles.
Q3: How quiet is the compressor during operation?
Thanks to our optimized screw rotor design and high-quality soundproof enclosure, the compressor operates quietly at levels as low as 65 dB.
Q4: Can this compressor be configured for custom voltage?
Yes, while our standard configuration is 380V 3PH 50HZ, other custom voltages can be accommodated to suit your local facility requirements.
Q5: What is the warranty coverage for this product?
We offer a 1-Year Motor Warranty to give you complete confidence in the quality, durability, and reliability of the unit.
Q6: What makes the setup process fast and simple?
Our compressors feature a Plug-and-Play design. They are pre-assembled and fully integrated with built-in cooling systems, ensuring immediate and quick installation.
