| Model | XZV-8A | XZV-11A | XZV-15A | XZV-18A | XZV-22A | XZV-30A | XZV-37A | XZV-45A | XZV-55A | XZV-75A | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Free Air Delivery / Discharge Air Pressure (m³/min / MPa) |
0.7 MPa | 1.1 | 1.8 | 2.5 | 3.0 | 3.7 | 5.0 | 6.5 | 7.4 | 10.0 | 13.4 |
| 0.8 MPa | 1.0 | 1.7 | 2.3 | 2.9 | 3.5 | 4.8 | 6.2 | 7.0 | 9.6 | 12.6 | |
| 1.0 MPa | 0.9 | 1.5 | 2.0 | 2.7 | 3.1 | 4.3 | 5.6 | 6.2 | 8.5 | 11.2 | |
| 1.3 MPa | 0.7 | 1.2 | 1.7 | 2.2 | 2.6 | 3.6 | 4.5 | 5.5 | 7.2 | 9.8 | |
| Air Supply Temperature | ≤ ambient temperature +8~15 °C | ||||||||||
| Motor Spec | Power (kW/HP) | 7.5/10 | 11/15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 | 75/100 |
| Start Method | VSD Starter | ||||||||||
| Voltage (V/Hz) | 380V 3PH 50HZ (380V-3PH-60HZ / 460V-3PH-60HZ / 220V-3PH-60HZ / 400V-3PH-50HZ / 6000V-3PH-50HZ or custom) | ||||||||||
| Drive Method | Coupling transmission | ||||||||||
| Oil Content (PPM) | ≤ 3 | ||||||||||
| Connector Inch | 3/4" | 3/4" | 1" | 1" | 1" | 1 1/4" | 1 1/4" | 1 1/2" | 1 1/2" | 2" | |
| Noise (dB ± 2) | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | 78 | |
| Dimensions | Length (mm) | 900 | 1100 | 1100 | 1060 | 1060 | 1060 | 1500 | 1500 | 1800 | 1900 |
| Width (mm) | 700 | 750 | 750 | 820 | 820 | 820 | 1000 | 1000 | 1230 | 1230 | |
| Height (mm) | 930 | 1000 | 1000 | 1220 | 1220 | 1220 | 1290 | 1290 | 1570 | 1570 | |
| Weight (kg) | 140 | 200 | 210 | 235 | 296 | 336 | 443 | 466 | 834 | 917 | |
