| XZV-Series Technical Parameters: | |||||||||||
| Model | XZV-8A | XZV-11A | XZV-15A | XZV-18A | XZV-22A | XZV-30A | XZV-37A | XZV-45A | XZV-55A | XZV-75A | |
| Free Air Delivery / Discharge Air Pressure (m³/min / MPa) |
0.7 MPa | 1.1 | 1.8 | 2.5 | 3.0 | 3.7 | 5.0 | 6.5 | 7.4 | 10.0 | 13.4 |
| 0.8 MPa | 1.0 | 1.7 | 2.3 | 2.9 | 3.5 | 4.8 | 6.2 | 7.0 | 9.6 | 12.6 | |
| 1.0 MPa | 0.9 | 1.5 | 2.0 | 2.7 | 3.1 | 4.3 | 5.6 | 6.2 | 8.5 | 11.2 | |
| 1.3 MPa | 0.7 | 1.2 | 1.7 | 2.2 | 2.6 | 3.6 | 4.5 | 5.5 | 7.2 | 9.8 | |
| Air Supply Temperature | ≤ Ambient Temperature + 8 ~ 15°C | ||||||||||
| Motor | Power (kW/HP) | 7.5/10 | 11/15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 | 75/100 |
| Start Method | VSD Starter | ||||||||||
| Voltage (V/Hz) | 380V 3PH 50HZ (380V-3PH-60HZ / 460V-3PH-60HZ / 220V-3PH-60HZ / 400V-3PH-50HZ / 6000V-3PH-50HZ / other voltages customized) | ||||||||||
| Drive Method | Coupling Transmission | ||||||||||
| Oil Content (PPM) | ≤ 3 | ||||||||||
| Connector Inch | 3/4" | 3/4" | 1" | 1" | 1" | 1 1/4" | 1 1/4" | 1 1/2" | 1 1/2" | 2" | |
| Noise (dB ± 2) | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | 78 | |
| Dimension | Length (mm) | 900 | 1100 | 1100 | 1060 | 1060 | 1060 | 1500 | 1500 | 1800 | 1900 |
| Width (mm) | 700 | 750 | 750 | 820 | 820 | 820 | 1000 | 1000 | 1230 | 1230 | |
| Height (mm) | 930 | 1000 | 1000 | 1220 | 1220 | 1220 | 1290 | 1290 | 1570 | 1570 | |
| Weight (kg) | 140 | 200 | 210 | 235 | 296 | 336 | 443 | 466 | 834 | 917 | |
A1 We are a factory and currently operate 2 factories.
A2 We provide a 13-month warranty starting from the delivery date.
A3 Yes, of course, spare parts will be provided.
A4 For standard 380V 50HZ configurations, we can deliver the goods within 10 days. For other custom voltages or colors, delivery will be arranged within 30 days.
A5 Yes, we have a professional design team and highly welcome OEM orders.
