ODM Cheap 7.5-132 KW Frequency Inverter PM VSD Rotary Screw Air Compressor Manufacturer, Exporters

✅ Full Power Range: Covers 7.5kW-250kW models to meet diverse industrial air demands. ✅ Multi-Pressure Compatibility: Supports working pressures from 0.7MPa to 1.55MPa. ✅ Low Noise Design: Noise levels range from 66±2 to 75±2 dB(A) for quiet operation. ✅ Efficient Direct Drive: Coaxial/direct link transmission eliminates belt losses for high efficiency. ✅ Soft Start System: Frequency conversion soft start reduces impact on power grids and equipment.

Send Inquiry

Product Description

Technical Specifications (Models 10A - 60A)

Model	10A	15A	20A	25A	30A	40A	50A	60A
Free Air Delivery / Discharge Pressure (m³/min / MPa)	1.2 / 0.7	1.65 / 0.7	2.5 / 0.7	3.2 / 0.7	3.8 / 0.7	5.3 / 0.7	6.8 / 0.7	7.4 / 0.7
	1.1 / 0.8	1.5 / 0.8	2.3 / 0.8	3.0 / 0.8	3.6 / 0.8	5.0 / 0.8	6.2 / 0.8	7.0 / 0.8
	0.95 / 1.0	1.3 / 1.0	2.1 / 1.0	2.7 / 1.0	3.2 / 1.0	4.5 / 1.0	5.6 / 1.0	6.2 / 1.0
	0.8 / 1.25	1.1 / 1.25	1.9 / 1.25	2.4 / 1.25	2.7 / 1.25	4.0 / 1.25	5.0 / 1.25	5.6 / 1.25
Lubricating Oil Qty (L)	4	7.5	14	14	14	30	30	30
Driving Mode	Direct drive
Power Supply	380V/50Hz/3P or customized
Power (kW)	7.5	11	15	18.5	22	30	37	45
Startup Mode	Y-Δ start-up
Dimension (mm)	850670870	1100750920		12508501160			135010001190
Outlet Diameter	G¼	G¼	G1	G1	G1	G1¼	G1¼	G1¼

Technical Specifications (Models 75A - 350A)

Model	75A	100A	120A	150A	175A	200A	250A	300A	350A
Free Air Delivery / Discharge Pressure (m³/min / MPa)	10.0 / 0.7	13.4 / 0.7	16.2 / 0.7	21.0 / 0.7	24.5 / 0.7	28.7 / 0.7	32.0 / 0.7	36.0 / 0.7	42.0 / 0.7
	9.6 / 0.8	12.6 / 0.8	15.0 / 0.8	19.8 / 0.8	23.2 / 0.8	27.6 / 0.8	30.4 / 0.8	34.3 / 0.8	40.5 / 0.8
	8.5 / 1.0	11.2 / 1.0	13.8 / 1.0	17.4 / 1.0	20.5 / 1.0	24.6 / 1.0	27.4 / 1.0	30.2 / 1.0	38.2 / 1.0
	7.6 / 1.25	10.0 / 1.25	12.3 / 1.25	14.8 / 1.25	17.4 / 1.25	21.5 / 1.25	24.8 / 1.25	27.7 / 1.25	34.5 / 1.25
Lubricating Oil Qty (L)	65	65	72	90	90	110	110	125	125
Driving Mode	Direct drive
Power (kW)	55	75	90	110	132	160	185	220	250
Startup Mode	Y-Δ Start-up
Dimension (mm)	180012301570	190012301570		230014701840		265016502045		330021002190
Weight (kg)	1073	1272	1327	1801	1848	2400	2600	3100	3300
Outlet Diameter	G2	G2	G2	G2½	G2½	G2½	G2½	DN100	DN100

Frequently Asked Questions

? What is the standard driving mode for these air compressors?

All models in this series utilize direct drive mode to optimize efficiency, lower vibration, and minimize transmission loss.

? Can the power supply configurations be customized?

Yes, the standard power supply configuration is 380V/50Hz/3P, but customizable configurations are available to meet your local industrial voltage standards.

? What type of startup system do these compressors use?

These compressors utilize Y-Δ (Star-Delta) start-up mode, which reduces the starting current demand on your electrical system.

? How does the lubricating oil capacity vary across different models?

Lubricating oil capacity ranges from 4 liters for the compact 10A model up to 125 liters for the high-capacity 350A industrial model. Refer to the specifications table for detailed sizing.

? What is the discharge pressure range for the 10A to 60A models?

Models 10A through 60A support discharge pressures of 0.7 MPa, 0.8 MPa, 1.0 MPa, and up to 1.25 MPa.

? What outlet connection options are available?

Smaller models (10A-30A) use G¼ to G1 thread connections, mid-range models use G1¼ to G2½ connections, and the largest models (300A-350A) feature DN100 flange connections.
