  SHORT DESCRIPTION:
  1. Two-stage compression permanent magnet frequency conversion design, energy-saving and efficient.
  2. 100% oil-free pure air output, eco-friendly with durable aviation coating impeller.
  3. Large filter box & top flip door, easy filter replacement and daily maintenance.
  4. Built-in muffler, low-noise stable operation with long service life.
Send Inquiry

Product Description

1
Supplies 100% oil-free pure compressed air.
2
Fits medical, pharmaceutical, precision electronics, food & beverage industries.
3
Low-speed fans + large plate coolers reduce airflow friction.
4
Creates quiet and comfortable working conditions.

Product Features

Air-End
  • Branded air-end with mature R&D experience
  • High-tech air-end, delivering average 8-10% energy saving
  • Self-designed gearbox for high reliability & durability
High Efficiency & Save Energy
  • High-efficiency energy-saving intake valve, reduces unloading pressure and avoids energy waste
  • New oil tank design with lower pressure drop and less energy consumption
  • Shortest piping system to minimize pressure drop
  • Oversized air/oil separator to reduce pressure drop
  • Optimized cooler design with fewer elbows
Reliability & Safety
  • Oversized cooler for lower operating temperature
  • Safe and reliable filter system
  • Integrated fan, stable and high efficiency
  • Reinforced cabinet, strong & safe
Low noise & low vibration
  • Low-noise & low-vibration air-end
  • Motor with noise reduction baffle
Easy Installation & Operation
  • Compressor pre-filled with lubricating oil before shipping, ready to run after installation and power-on
  • PLC intelligent control system with reminder & record function, clearly showing compressor status
  • User-friendly design, common maintenance can be done by opening the door
  • Cooler and fan are easy to clean
Smart controller panel
  • Touch screen display
  • PLC intelligent control system with reminder & record function, clearly showing compressor status
  • Customizable language versions
Branded PLC
  • Origin from France
  • PLC intelligent control system
  • Protect your compressor during operation

Technical Specifications

Model EOF-55W EOF-75W EOF-90W EOF-110W EOF-132W EOF-145W EOF-160W EOF-200W EOF-250W EOF-315W
Free air delivery/Discharge air pressure (M³/min/ Mpa) 0.75 Mpa 8.8/0.75 11.9/0.75 14.3/0.75 19.1/0.75 21.9/0.75 23.5/0.75 28.3/0.75 36.1/0.75 43.1/0.75 46.4/0.75
0.85 Mpa 7.9/0.85 11.2/0.85 13.5/0.85 17.1/0.85 19.6/0.85 21.7/0.85 26.1/0.85 33.1/0.85 41.0/0.85 43.0/0.85
1.0 Mpa 7.3/1.0 10.7/1.0 12.7/1.0 16.0/1.0 18.9/1.0 20.1/1.0 24.2/1.0 30.4/1.0 37.4/1.0 41.0/1.0
Motor Power (kw/hp) 55/75 75/100 90/120 110/150 132/175 145/200 160/215 200/270 250/355 315/420
Start method VSD Starter/star triangle
Voltage (v/hz) 380V 3PH 50HZ (380V-3PH-60HZ/ 460V- 3PH- 60HZ/ 220V- 3PH-60HZ/ 400V-3PH-50HZ//other voltages customized)
Drive method direct drive
Connector inch 2" 2" DN65 DN65 DN80 DN100 DN100 DN100 DN100 DN150
Dimension length mm 2630 2630 2630 2630 3200 3200 3200 3200 3500 3500
width mm 1788 1788 1788 1788 1980 1980 1980 1980 2100 2100
height mm 1900 1900 1900 1900 2000 2000 2000 2000 2200 2200
Weight (kg) 2300 2500 2800 2980 3100 3300 3500 3800 4200 4800

Frequently Asked Questions

What are the advantages of the air end?
Equipped with premium branded air end, saving 8%-10% energy. Self-designed gearbox ensures high stability and long service life.
How does the compressor save energy?
Optimized intake valve, low-resistance tank, short piping and oversized separator reduce pressure drop, realizing low power consumption.
Is the machine stable and safe for long-time operation?
Yes. Oversized cooler, reliable filter system, integrated fan and reinforced cabinet ensure low temperature, low failure rate and safe stable operation.
Is the machine low noise and low vibration?
Yes. Low-noise & low-vibration air end plus motor noise reduction baffle create a quiet and comfortable working environment.
Is installation and maintenance easy?
Very easy. Pre-filled with lubricating oil for plug-and-play use. Flip door design allows quick maintenance, and core parts are easy to clean.
What features does the control system have?
Adopts French PLC and intelligent touch screen. Supports real-time monitoring, data recording, fault reminder and multi-language switching with full operation protection.
