Constant pressure control provides significant energy savings, keeping pressure fluctuations within ±0.01 MPa.
The typical set temperature is 81°C, ensuring optimal lubrication performance while preventing sudden shutdowns caused by high temperatures.
Features a double-shell design with an oil passageway between the inner and outer shells. This utilizes the compressor's own lubrication system to circulate cooling through the oil passageway, eliminating contact with external cooling air and making it ideal for use in dusty environments.
| XZV- series technical parameters (Models 10A - 75A) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | 10A | 15A | 20A | 25A | 30A | 40A | X50A | 60A | 75A | |
| Free air delivery/Discharge air pressure (M³/min/ Mpa) | 0.7 Mpa | 1.1 | 1.65 | 2.5 | 3.0 | 3.7 | 5.0 | 6.5 | 8.0 | 10.8 |
| 0.8 Mpa | 1.0 | 1.5 | 2.3 | 2.9 | 3.5 | 4.8 | 6.2 | 7.5 | 10.2 | |
| 1.0 Mpa | 0.9 | 1.53 | 2.1 | 2.7 | 3.1 | 4.3 | 5.6 | 6.8 | 9.0 | |
| 1.25 Mpa | 0.8 | 1.1 | 1.7 | 2.4 | 2.7 | 4.0 | 5.0 | 5.6 | 7.6 | |
| Air supply temperature | ≤ ambient temperature +8~15°C | |||||||||
| Motor | Power (kw/hp) | 7.5/10 | 11/15 | 15/20 | 18.5/25 | 22/30 | 30/40 | 37/50 | 45/60 | 55/75 |
| Start method | Y-Δ Starter | |||||||||
| Voltage (v/hz) | 380V 3PH 50HZ (380V-3PH-60HZ/ 460V- 3PH- 60HZ/ 220V- 3PH-60HZ/ 400V-3PH-50HZ/6000V-3PH-50HZ/other voltages customized) | |||||||||
| Drive method | Direct Drive | |||||||||
| Oil content (PPM) | ≤ 3 | |||||||||
| Connector inch | 3/4" | 3/4" | 1" | 1" | 1" | 1 1/4" | 1 1/4" | 1 1/2" | 1 1/2" | |
| Noise (Db) ±2 | 66 | 68 | 68 | 68 | 68 | 68 | 72 | 72 | 75 | |
| Dimension | length mm | 850 | 1100 | 1100 | 1250 | 1250 | 1250 | 1350 | 1350 | 1800 |
| width mm | 670 | 750 | 750 | 850 | 850 | 850 | 1000 | 1000 | 1230 | |
| height mm | 870 | 920 | 920 | 1160 | 1160 | 1160 | 1190 | 1190 | 1570 | |
| Weight (kg) | 178 | 260 | 267 | 310 | 396 | 450 | 586 | 593 | 1073 | |
| XZV- series technical parameters (Models 100A - 350A) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | 100A | 120A | 150A | 175A | 200A | 250A | 300A | 350A | |
| Free air delivery/Discharge air pressure (M³/min/ Mpa) | 0.7 Mpa | 13.4 | 16.2 | 21.0 | 24.5 | 28.7 | 32.0 | 36.0 | 42.0 |
| 0.8 Mpa | 12.6 | 15.0 | 19.8 | 23.2 | 27.6 | 30.4 | 34.3 | 40.5 | |
| 1.0 Mpa | 11.2 | 13.8 | 17.4 | 20.5 | 24.6 | 27.4 | 30.2 | 38.2 | |
| 1.25 Mpa | 10.0 | 12.3 | 14.8 | 17.4 | 21.5 | 24.8 | 27.7 | 34.5 | |
| Air supply temperature | ≤ ambient temperature +8~15°C | ||||||||
| Motor | Power (kw/hp) | 75/100 | 90/120 | 110/150 | 132/175 | 160/200 | 185/250 | 220/300 | 250/350 |
| Start method | Y-Δ Starter | ||||||||
| Voltage (v/hz) | 380V 3PH 50HZ (380V-3PH-60HZ/ 460V- 3PH- 60HZ/ 220V- 3PH-60HZ/ 400V-3PH-50HZ/6000V-3PH-50HZ/other voltages customized) | ||||||||
| Drive method | Direct Drive | ||||||||
| Oil content (PPM) | ≤ 3 | ||||||||
| Connector inch | 2" | 2" | 2 1/4" | 2 1/2" | 2 1/2" | 2 1/2" | DN100 | DN100 | |
| Noise (Db) ±2 | 78 | 85 | 85 | 85 | 88 | 88 | 90 | 90 | |
| Dimension | length mm | 1900 | 1900 | 2300 | 2300 | 2650 | 2650 | 3300 | 3300 |
| width mm | 1230 | 1230 | 1470 | 1470 | 1650 | 1650 | 2100 | 2100 | |
| height mm | 1570 | 1570 | 1840 | 1840 | 2045 | 2045 | 2045 | 2190 | |
| Weight (kg) | 1171 | 1327 | 1801 | 1848 | 2400 | 2600 | 3100 | 3300 | |
Q1. How about the quality of your compressor?
Good-quality with 21 years experience.
Q2. Could you send the machine to overseas?
Yes, of course! Please tell me your port.
Q3. Could you make a certificate of original for me?
Yes, I will make based on your country.
Q4. What material would you use to pack your machine?
We will use a wooden to pack our compressor.
Q5. Could you take a photo of the machine before the transportation?
OK, I will take videos and photos for you!
Q6. Which kinds of motor do your compressor use?
Our compressor uses PM motor and inverter.
