1.5-500 m3/min  heatless regenerative adsorption for drying compressed air
The heatless regenerative adsorption compressed air dryer is specially designed for high-quality dry compressed air customers. It is suitable for various types of air compressors from 0.6 cubic to 60 cubic meters and can be used in all production systems.
Design conditions
Flow range: 1.5-500 m3/min
Pressure range: 0.6-1.0 MPa
Intake temp:,s:;45it
Regenerated gas volume: spoon 5%
Working cycle: 4-20 minutes
Pressure dew point: -20 seven, -40 it
Intake oil content:,s:;0.1 PPM Adsorbent: alumina + molecular sieve
Power supply: 220V /1Ph/50HZ
＊High pressure and stainless steel can be customized.
*Customization is welcome for above 1.0MPa.

Send Inquiry

Product Description

Product Specification
Model Flow Power Voltage Connection size Length mm Width mm Height mm
OSGHL-1NF 1.5 0.2 220-230V/50-60HZ 3/4" 680 400 1400
OSGHL-2NF 2.5 0.2 220-230V/50-60HZ 3/4" 800 400 1700
OSGHL-3NF 3.8 0.2 220-230V/50-60HZ 1" 860 500 1750
OSGHL-6NF 6.8 0.2 220-230V/50-60HZ 1 1/2" 990 550 1830
OSGHL-8NF 8.5 0.2 220-230V/50-60HZ 2" 1080 600 1600
OSGHL-12NF 12 0.2 220-230V/50-60HZ 2" 1080 600 1880
OSGHL-15NF 16 0.2 220-230V/50-60HZ 2" 1200 650 2000
OSGHL-20NF 22 0.2 220-230V/50-60HZ DN65 1350 680 2100
OSGHL-25NF 27 0.2 220-230V/50-60HZ DN80 1450 700 2400
OSGHL-30NF 32 0.2 220-230V/50-60HZ DN80 1550 750 2400
OSGHL-40NF 38 0.2 220-230V/50-60HZ DN100 1700 800 2400
OSGHL-45NF 45 0.2 220-230V/50-60HZ DN100 1800 800 2500
OSGHL-55NF 55 0.2 220-230V/50-60HZ DN125 1900 850 2550
OSGHL-65NF 65 0.2 220-230V/50-60HZ DN125 2100 900 2650
OSGHL-85NF 85 0.2 220-230V/50-60HZ DN125 2300 1000 2800
OSGHL-110NF 110 0.2 220-230V/50-60HZ DN150 2400 1100 2900
OSGHL-135NF 135 0.2 220-230V/50-60HZ DN150 2550 1200 3000
OSGHL-160NF 160 0.2 220-230V/50-60HZ DN200 2650 1350 3050
OSGHL-200NF 200 0.2 220-230V/50-60HZ DN200 2800 1450 3050
Advantage
Reliable Design
The bottom of the adsorption tower adopts supporting balls to make the air flow distribution more uniform, which can prevent the adsorbent at the bottom from soaking in water and prolong the life of the adsorbent; with the specially designed stainless copper shunt, the pressure loss can be greatly reduced.
High-Performance Adsorbent
Special customized high-performance adsorbent can achieve excellent neon point.
Pneumatic Valves
The full range of standard configurations are commercially available pneumatic valves, which operate. The reliability and pressure loss are much better than membrane valves, solenoid valves, etc.
Various Control Options
A full range of standard microcomputer controllers; Optional: Siemens, ABB and other brands of PLC, touch screen, etc.; can meet the user's various communication requirements from Proflbus, Modbus, to Ethernet connection.
Energy Saving
The optional HDC dew point energy-saving control system can prolong the adsorption time and reduce the comprehensive energy efficiency to below 75% in the working condition of load fluctuation.
Frequently Asked Questions (FAQ)
What models and flows are available in this product range?
Models range from OSGHL-1NF with a flow rate of 1.5 to OSGHL-200NF with a flow rate of 200. The standard operating voltage across all models is 220-230V/50-60HZ.
How does the reliable design prevent adsorbent damage?
The bottom of the adsorption tower uses specially positioned supporting balls to distribute air flow uniformly. This prevents the adsorbent from soaking in water, which significantly extends its service life.
What makes the pneumatic valves superior to membrane or solenoid valves?
The system features commercially available pneumatic valves as standard configurations. These offer much higher operational reliability and significantly lower pressure loss compared to standard membrane or solenoid options.
What standard and optional control systems can I choose from?
A full range of standard microcomputer controllers is provided. Users also have the option to upgrade to Siemens, ABB, and other leading brand PLCs or touch screens to support communication protocols like Proflbus, Modbus, and Ethernet.
How does the HDC dew point system help save energy?
The optional HDC dew point energy-saving control system monitors operation, allowing the unit to extend adsorption time and reduce comprehensive energy efficiency to below 75% under fluctuating load conditions.
